Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables

Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables manufactured at our factory. High-quality and reliable for all your industrial needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Kvvp
Material Shape
Round Wire
Range of Application
Control and Protection Circuits
Certification
ISO9001, CE, CCC, RoHS, VDE
Brand
Feiya
Rate Voltage
450/750V
Temperature Range
0 Degree Till +70 Degree
OEM
Yes
Transport Package
Wooden Box Packing or Pallet Shipping Containers
Specification
copper/pvc
Trademark
Feiya
Origin
China
HS Code
854449210
Production Capacity
50K Meter Per Year

Product Description

Cu core PVC insulation PVC sheathed control cables


Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables




Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables



Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables



Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables


Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables


Type:KVVP

Application: Laid up indoors,in the channels,in the pipes and fixed places where screening is not required.

It is manufactured acconding to GB/T 9330-2008,GB/T 19666-2005 standard.

Application

PVC insulation and sheath control cables are used in control and protection circuits under AC rated 450/750V.

Use conditions

1.Rated voltage U0/U:450/750V
2.Max.allowable working temperature is 70ºC;
3.The laid-up temperature should not be less than 0ºC,recommended allowable bending radius:
4.Not less than 6 times of diameter without armoring layer;
5.Not less than 12 times of diameter with armoring or screening layer;
6.Not less than 6 times of diameter for soft cable with screening layer.

Product spec

Type
Rated voltage V Conductor nominal section mm²
0.5 0.75 1.0 1.5 2.5 4 6
KVV 450/750V -- 2~37 2~14
KVVP -- 2~37 4~14
KVVP2 -- 4~37 4~14
KVV22 -- 7~37 4~37 4~14
KVVP22 -- 7~37 4~37 4~14
KVVP2-22 -- 7~37 4~37 4~14
KVVR 2~37 --
KVVRP 2~37       --
:,  Note:The same for flame-retardant cables and fire-resistance cables



Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables




Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables



Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables




Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables





Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables


Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables




Kvvp PVC Insulation & Sheathed Copper-Wire Braid Screening Control Cables


FAQ

Q1:Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable CO., LTD. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable CO., LTD. manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable,PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable,coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3:Which standards do you comply with when you produce the electrical wires and cables ?

A3: We have passed ISO9001:2000 and ISO140001:2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5:How much the Courier freight will be for the samples?

A5:Courier freight depends on the quantity,weight and carton size and your area.
