Description:
Conductor: Strand Bare Copper wire
Insulation:PVC
Color:Black,White,Red,Yellow,Blue,and etc.,
Voltage Rating:300V/500V
Number of Cores: single core
Temperature Rating:-30~ +70ºC
Reference Standard:IEC60227
Typical Application:
1.For Building Wiring, housing wiring,
2.For internal wiring of electronic and electrical equipment or power cord
Best Feature:
RV(60227IEC06) 300/500V Single Core PVC InsulationFlexible Electric Wire
made by elesuncable, is feature for high quality raw material and stable performance.
The Bare copper is imported from Chili, and the purity can reach 99.99%, The insulation material is totally original. It has good resistance against oil, acid, moisture, and mildew.
RV(60227IEC06) 300/500V Single Core PVC Insulation FlexibleElectric Wire
| |||||
Nominal Cross( mm²) | Conductor Structure(mm) | Insulation Thickness (mm) | O.D. Of Cable(mm) | Max Resistance @20ºC(Ω/KM) | Min. Resistance @70ºC(Ω/KM) |
0.5 | 1/0.80 | 0.6 | 2.0 | 36.0 | 0.015 |
0.75 | 1/0.97 | 0.6 | 2.17 | 24.5 | 0.012 |
1.0 | 1/1.13 | 0.6 | 2.33 | 18.1 | 0.011 |
Q1: Are you a manufacture or a trading company? A:We are a professionly cable manufacture with more than 20 years production experience.
Q2:What kind of cable do you produce?
A: We specialized in producing Coaxial Cable,Cable Assembly,Network cable,electric wire,Network Cable.
We also provide cable assembly according to customers requirement.
Q3:What's your MOQ? Can you offer free samples?
A: Our MOQ is 2KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.
Q4: What's your delivery time?
A:Normally, our delivery time is 7-10 days after received deposit or payment,it base on the quantity of the order.
Q5: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.
Q6:What's your trade term?
A: We accept FOB ShangHai or Ningbo,Guanghzou,Shenzhen,CFR,CIF,EXW term
Q7: Where is your factory located? How can I visit there?
A: Our factory is located in Zhenjiang City,Jiangsu Province,China.
1 hour drive from Nanjing Airport
3 hours drive or 1 and half an hour by high speed rail to railway station from shanghai.
Q8:Do you accept OEM/ODM
A:Sure.we accept.
Why choose us:
1.We have more than 20 years experience for communication cables and cable assembly.
2.We own R&D team more than 10 engineers,give you strongest support !
3.Fast delivery time ,we have big capacity with short production time.
4.Factory directly sale - Most Competitive price than average level .
5.We have very strict quality control system during the whole production process.We always inspect all the goods before shipment.
6.IATF 16949 /UL certification approved.
