Basic Info.
Model NO.
Copper wire
Conductor Material
Copper
Sheath Material
Nylon or PVC
Insulation Material
PVC
Material Shape
Round Wire
Range of Application
Building
Certification
ISO9001, CCC
Brand
Zoom Link
Type of Conductor
Solid , Stranded, Flexible
Insulation
PVC
Voltage
300/500V, 450/750V
MOQ
20000m
OEM or ODM
Ok
Samples
Free
Type of Company
Manufacture
Price
Factory Price
Quality
100% Test Each Drum
Delivery Time
30 Days
Transport Package
Coil
Specification
1 sq mm to 10 sq mm
Trademark
ZML
Origin
China
Production Capacity
200000 Per Day
Packaging & Delivery
Package Size
100.00cm * 100.00cm * 100.00cm
Package Gross Weight
800.000kg
Product Description
1.5 mm 2.5 mm 4mm Single Core Cable 6 Sq mm Copper Wire Prices electric wire prices list
PLEASE SEND YOUR ENQUIRY !
1. Application
The PVC insulated wires belong to the series of laying wires, which are mainly suitable for laying at the fixed places. They are
widely used as connectors of driving, lighting,
electric equipment, instrument and telecommunication equipment with rated voltage up to 450/750V.Part of the plastic insulated
wires are used at the equipment with AC rated voltage up to 300V
2. Standard
IEC 60227,IEC 60228,IEC 60332,GB/T 5023,BS 6500,BS 6004,VDE 0281,0282 ,UL 83, AS/NZS 5000. etc.
The PVC insulated wires belong to the series of laying wires, which are mainly suitable for laying at the fixed places. They are
widely used as connectors of driving, lighting,
electric equipment, instrument and telecommunication equipment with rated voltage up to 450/750V.Part of the plastic insulated
wires are used at the equipment with AC rated voltage up to 300V
2. Standard
IEC 60227,IEC 60228,IEC 60332,GB/T 5023,BS 6500,BS 6004,VDE 0281,0282 ,UL 83, AS/NZS 5000. etc.
3.Specification
Conductor material: Copper, Aluminum
Conductor structure: Solid, strand, flexible
Insulation material: PVC,XLPE,PE
Sheath material : PVC, Nylon
Core : 1,2,3,4,5
Shape of wire : round, flat
Voltage :300-1000V
4. Model: TW,THHN, THW, H07V-K, H07V-U, BV wire
BV WIRE, H07V-K, H07V-U
TW, THW
Conductor structure: Solid, strand, flexible
Insulation material: PVC,XLPE,PE
Sheath material : PVC, Nylon
Core : 1,2,3,4,5
Shape of wire : round, flat
Voltage :300-1000V
4. Model: TW,THHN, THW, H07V-K, H07V-U, BV wire
BV WIRE, H07V-K, H07V-U
| Nominal section (mm2) | N/Dia (mm) | Max outer Dia(mm) | Reference Weight (kg/km) | Conductor resistance at 20ºC≤(Ω/km) | ||
| copper | Aluminum | copper | Aluminum | |||
| 1.5(class 1) | 1/1.38 | 3.3 | 20.3 | 12.1 | ||
| 1.5(class2) | 7/0.52 | 3.5 | 21.6 | 12.1 | ||
| 2.5(class 1) | 1/1.78 | 3.9 | 31.6 | 17 | 7.41 | 11.80 |
| 2.5(class2) | 7/0.68 | 4.2 | 34.8 | 7.41 | ||
| 4(class 1) | 1/2.55 | 4.4 | 47.1 | 22 | 4.61 | 7.39 |
| 4(class2) | 7/0.85 | 4.8 | 50.3 | 4.61 | ||
| 6(class 1) | 1/2.76 | 4.8 | 50.3 | 29 | 3.08 | 4.91 |
| 6(class2) | 7/1.04 | 5.4 | 71.2 | 3.08 | 3.08 | |
| 10 | 7/1.35 | 7.0 | 119 | 62 | 1.83 | 1.91 |
| 16 | 7/1.70 | 8.0 | 179 | 78 | 1.15 | 1.20 |
| 25 | 7/2.04 | 10.0 | 281 | 118 | 0.727 | 0.868 |
| 35 | 7/2.52 | 11.5 | 381 | 156 | 0.524 | 0.641 |
| 50 | 19/1.78 | 13 | 521 | 215 | 0.387 | 0.443 |
TW, THW
