Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm

Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable and Electrical Copper Wire 3mm. Top-quality products direct from our factory. Buy now for the best deals!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Technical Parameter
  • Company Profile
  • Product details
  • Application scenario
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
RVV
Conductor Material
Copper
Sheath Material
PVC
Insulation Material
XLPE
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
CE, CCC, RoHS
Brand
Huayuan
Conductor
Copper
Voltage
0.6/1kv
Maq
100meter
Application Scope
Home Decoration, Home Wiring, Engineering Projects
Transport Package
Packing
Specification
RVV
Trademark
Huayuan
Origin
Shenyang, Liaoning, China
HS Code
8544492100
Production Capacity
100000meter/Year

Packaging & Delivery

Package Size
30.00cm * 25.00cm * 25.00cm
Package Gross Weight
10.000kg

Product Description





Product Description

Product name ABC XLPE0.6/1KV power cable
Conductor Copper
Insulation material XLPE
Rated voltage 0.6/1KV
Colour Black
Application site Home decoration electricity, urban electricity
Size 3C 10 AWG
Other specifications can consult customer service
Starting batch 100meters


Technical Parameter

cross-section(mm²) Insulation thickness(mm) Inner sheath thickness(mm) Approximate outer diameter of cable(mm)
1C 2C 3C 4C 5C 1C 2C 3C 4C 5C
1.5 0.7 1.4 1.8 1.8 1.8 1.8 5.9 10.4 10.8 11.6 12.4
2.5 0.7 1.4 1.8 1.8 1.8 1.8 6.3 11.2 11.7 12.6 13.5
4 0.7 1.4 1.8 1.8 1.8 1.8 6.8 12.2 12.7 13.7 14.8
6 0.7 1.4 1.8 1.8 1.8 1.8 7.3 13.2 13.8 14.9 16.1
10 0.7 1.4 1.8 1.8 1.8 1.8 8.6 15.8 16.6 18.0  19.6
16 0.7 1.4 1.8 1.8 1.8 1.8 9.7 17.9 18.9 20.6 22.4
25 0.9 1.4 1.8 1.8 1.8 1.8 11.4 21.3 22.6 24.8 27.2
35 0.9 1.4 1.8 1.8 1.8 1.8 12.5 23.6 25.1 27.6 30.5
50 1.0  1.4 1.8 1.8 1.8 1.8 14.1 26.7 28.5 31.6 35.0
70 1.1 1.5 1.9 2.0  2.1 2.3 16.2 31.0  33.2 36.8 10.8
95 1.1 1.5 2.1 2.2 2.3 2.4 18.3 35.1 37.6 41.8 46.4
120 1.2 1.6 2.2 2.3 2.4 2.6 20.2 39.0  41.8 46.5 51.7
150 1.4 1.7 2.3 2.4 2.6 2.8 22.3 43.3 46.4 51.6 57.4
185 1.6 1.7 2.5 2.6 2.8 3.0  24.8 48.2 51.7 57.6 64.1
240 1.7 1.8 2.7 2.8 3.0  3.3 27.9 54.3 58.3 64.9 72.3
300 1.8 1.9 2.9 3.0  3.3 3.5 30.7 60.0  64.4 71.8 80.0
400 2.0  2.0          34.3
500 2.2 2.0          38.6
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
RVV cable is a standard for differentiating wire diameters, also known as Brown & Sharpe wire gauges. This standardized wire gauge system was first used in the United States in 1857. The value in front of the AWG (e.g. 24AWG, 26AWG) indicates the number of holes through which the wire will pass before forming the final diameter. The higher the value, the higher the grade of the hole through which the wire passes, the smaller the diameter of the wire.


RVV Cable - Crosslinked Polyethylene (XLPE)

Conductor size standardization: Conductors for AWG cables
The dimensions are divided according to the AWG standard, which makes
The choice of conductor diameter is more standardized and regular
Mold.
Low conductor resistance: as specified by the AWG standard
Conductor size, therefore AWG cable conductor electricity
The resistance is relatively low, helping to reduce the power of the cable
Rate of loss.
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm

Company introduction
The company is committed to wire and cable manufacturing and wholesale sales, the company's products mature, to ensure product quality, to ensure after-sales and customer satisfaction, now operating a variety of wire and cable, but also support online customization



Company Profile



Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm



Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm



Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm
Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm


   Our company is a professional manufacturer of wires and cables in the Chinese wire and cable industry. It is a wire and cable manufacturer producing electronic and electrical equipment and electromechanical buildings in Shenyang, Liaoning Our company focuses on the innovation and research and development of wire and cable, special cable products.  At the beginning of the establishment of the enterprise, the founder of the enterprise managed the enterprise with the core   concept of "people-oriented, honest andinnovative, and leading service". The business philosophy of the enterprise was "honesty first, credibility first, quality first, and benefit sharing", guiding the development of the enterprise. With integrity as the heart, the enterprise gained trust from society, the market, customers, and colleagues. Deeply aware of the importance of talent, integrity, innovation, quality, and service to enterprises, we continuously develop and improve the enterprise, and adhere to the corporate strategy of "steady development, survival through competition, pragmatic innovation, and persistent integrity".                                                                                     Leading the way in the wire and cable industry in proposing "efficient feedback, quick response" The service concept of "dedicated service, best efficiency" enables the establishment of a green channel between supply and demand with customers, achieving a "win-win" situation. With the efforts of the enterprise to develop and grow, we will focus on strengthening the brand building of the enterprise, the construction of enterprise culture, the cultivation of enterprise talents, the improvement of enterprise services, and establish a good brand image of the enterprise and products. Huayuan Wire and Cable Manufacturing Co., Ltd. is willing to create a better future with excellent employees with high-quality products and excellent services.


Product details

Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm

AWG cables can use a variety of insulating materials, such as polyvinyl chloride (PVC), polyethylene (PE), cross-linked polyethylene (XLPE), etc., to meet different insulation requirements



Application scenario

Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm

Our Advantages

Rvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mmRvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mmRvv 2 * 1.0mm2 Electrical Wiring Insulated Cable, Electrical Copper Wire 3mm



FAQ

1.Are you a manufacturer or a trading company?

We are a production manufacturer, and we have our own cable factory in Shenyang, Liaoning Province, China. We only produce the best quality, and you can rest assured of the quality.

2.Can you produce and manufacture products according to customer requirements?

Yes, we can customize the product according to your requirements

3.What is your delivery time?

Regular products usually take seven to fifteen days, depending on the quantity of your order.

4.Can you send samples to check your quality?

Yes, the samples are free, and the shipping fee will be borne by you.
