Basic Info.
Certification
ISO, CCC, CE, RoHS, VDE
Model
BV/BVV/Bvr/Blv/Bvr
Brand
Feiya
Colour
Red/Green/Blue/Black/White/as Request
Flame Test
Yes
Core
Single Core and Multicores
Transport Package
Rolls or According to Cusotmers′ Reques
Specification
0.12 to 400mm2
Trademark
Fengda
Origin
Tianjin, China
HS Code
8544421900
Product Description
Executive standard
It is manufactured acconding to GB/T 5023-2008,JB/T 8734-2016 standards.(Equivalent national standard of IEC60227).
Application
B serie are used for fixed laying in engine devices of AC rated voltage 450/750V of lower, R serie are used for household electrical appliances ,small electrical tools, instruments and engine lighting of AC rated voltage 450/750V or lower.
Type of the cables
Type | Designation | Core No. | Production Range mm2 | Rated voltage |
60227IEC01(BV) | General purpose single core hard conductor cable without sheath | 1 | 1.5-400 | 450/750 |
60227IEC02(RV) | General purpose single core soft conductor cable without sheath | 1 | 1.5-240 | 450/750 |
60227IEC05(BV) | 70ºC Inner wiring purpose single core solid conductor cable without sheath 70ºC for conductor temperature | 1 | 0.5-1.0 | 300/500 |
60227IEC06(RV) | 70ºC Inner wiring purpose single core solid conductor cable without sheath 70ºC for conductor temperature | 1 | 0.5-1.0 | 300/500 |
60227IEC10(BVV) | Light type PVC sheath cable | 2-5 | 1.5-35 | 300/500 |
60227IEC52(RVV) | Light type PVC sheath soft wire | 2-3 | 0.5-0.75 | 300/300 |
60227IEC53(RVV) | General PVC sheath soft wire | 2-5 | 0.75-2.5 | 300/500 |
BV | Cu conductor PVC insulation cable | 1 | 0.75-1.0 | 300/500 |
BLV | Al conductor PVC insulation cable | 1 | 2.5-400 | 450/750 |
BVR | Cu conductor PVC insulation soft cable | 1 | 2.5-70 | 450/750 |
BVV | Cu conductor insulation and sheath circular cable | 1 | 0.75-10 | 300/500 |
BLVV | Al conductor insulation and sheath circular cable | 1 | 2.5-10 | 300/500 |
BVVB | Cu conductor insulation and sheath flat cable | 2-3 | 0.75-10 | 300/500 |
BLVVB | Al conductor insulation and sheath flat cable | 2-3 | 2.5-10 | 300/500 |
RVVP | Cu conductor PVC insulation sheath and shielded soft cable | 1-24 | 0.5-6 | 300/300 |
